30-40kW

Product Overview

1. The product mainly consists of human-computer interaction touch screen, card reader, energy metering module, charging module, communication module, charging interface, control module, and pile body

2. The charging station provides Ethernet for external use Multiple communication interfaces such as GPRS can achieve real-time communication with monitoring centers and operation management platforms, enabling data exchange such as remote signaling, telemetry, and remote control, and monitoring the status of charging stations in real time


3. Real time monitoring of charging station operation data, charging cable connection status, equipment fault alarm status during charging. Charging can be stopped immediately in case of abnormal connection or fault alarm, and can also be initiated by the user to ensure personal and vehicle safety during the charging process


4. The charging station has multiple protection functions, and the input and output have dual safety protection measures


5. Humanized interface display and control guidance function, making it convenient for customers to complete the charging process


6. Has good dust-proof and waterproof performance, suitable for outdoor installation and use


product design

• Adopting a 30/40kW constant power range of 300-1000V super constant power module, it has excellent performance at high temperatures and a wide constant power range, ensuring fast charging under high temperature conditions; The full load charging efficiency is 0.5% higher than the industry, greatly reducing operating costs;

• The standby power consumption of the entire machine is less than 0.1%, reducing operating costs;


• The output voltage range is wide from 200-1000V, suitable for more vehicle models and a wider range of application scenarios;


• High power density - smaller size and less footprint; Reasonable air duct design;


• It has protective functions such as short circuit, overheating, leakage, flame retardancy, lightning strike, emergency stop charging, AC input overvoltage and undervoltage, DC output overcurrent and undervoltage, output reverse connection and wrong connection;


• Customizable UI interface style according to customer needs.


Usage environment

• Altitude ≤ 2000 meters

• Equipment operating environment temperature -30 ℃~55 ℃

• Air relative humidity 5%~95%

• Outdoor operation, canopies can be installed above the equipment as needed

• Installation inclination not exceeding 5%


• Keep away from flammable and explosive materials around the pile body
